It is suitable for packing all kinds of irregular articles, sticky articles and solid objects.
Food: noodles, egg rolls, sausages, squid, bread, moon cakes, preserved fruit, soft candy, etc.
Chemical categories: soap, tape, etc.
Electrical switches: power strips, switches, etc
Other categories: essential oils, pocket notebooks, boxed pens, medicines, etc.
1. The whole machine is controlled by three servos;
2. Seven-inch touch screen display, easy operation and clear working status;
3. A variety of product parameters and formulas can be stored, which can be downloaded and used without repeated settings;
4. Automatic adjustment of bag length without manual setting;
5. Higher precision and accurate sealing and cutting position;
6. Stop position and print position can be set arbitrarily;
7. Simple mechanical structure, convenient and intuitive debugging and low after-sales maintenance cost;
8. The packaging range is expanded to adapt to a variety of product specifications;
9. In line with the structure of human engineering mechanics, can be convenient to quickly clean up,maintenance, overhaul of the machine;
10. Reduce the labor intensity of the operator, effectively improve production efficiency.
Model | HK-3000(Single jaw) | HK-3000(Double jaws) |
Package length | 120-500 mm | 60-350 mm |
Package width | 35-160 mm | 35-160 mm |
Package height | 5-60 mm | 5-60 mm |
Packing speed | 30-120 bags/min | 30-250 bags/min |
Film size | 90-400 mm | 90-400 mm |
Packaging film type | PP、PE、PVC、PS,EVA,PET、PVDC+PVC、OPP+ etc. | |
Type of power supply | 220V 50HZ | 220V 50HZ |
General power | 3.1 KW | 3.8 KW |
Weight | 350 Kg | 350 Kg |
Dimension | 4100 × 770 × 1100 mm | |
