Suitable for bagging small-format products—such as cube-shaped toast, sliced bread, waffles, and small cookies, as well as cosmetics and cards—using pre-made eight-side-seal or four-side-seal bags.
1. Equipped with a servo control system; the touchscreen HMI offers a clear display and simplifies maintenance;
2. Features an automatic product feeding and conveying system, facilitating seamless integration with automated production lines and reducing labor costs;
3. Utilizes photoelectric sensors for automatic detection and servo tracking; the system prevents bag opening if a positional deviation is detected, thereby maximizing packaging material savings;
4. Characterized by a high degree of automation, specialized design, high production efficiency, and a low failure rate.
Item | Specifications |
Packaging speed | 70 packs/min |
Package dimensions: Length | 100–220 mm |
Package dimensions: Width | 40–150 mm |
Package dimensions: Height | 20–90 mm |
Air supply | 6 kg/cm² |
Machine net weight | 500 kg |
Overall dimensions | 1850 x 970 x 1310 mm |
Power supply type | 220V 50Hz/60Hz |
Packaging material | OPP/CPP, PT/PE, KOP/CPP, aluminized film |
Total power | 9 kW |
